MVK-MPNIO F DI8/4 F DO4
Product may differ from image

MVK-MPNIO F DI8/4 F DO4

MVK ProfiNet/PROFIsafe Compact module, metal,
Art.No.: 55563
Weight: 1.1 kg
In production
 Product Comparison
List price per piece:

Accessories

You might also like

safe inputs/outputs up to cat.4/PLe (EN ISO 13849-1), up to SIL3 (IEC 61508), up to SILCL3 (IEC 62061)
FDI8/4 DO4 (IRT)
Ethernet 10/100 Mbit/s; Push Pull RJ45 Data connector
Push Pull Power connector, max. 12 A
M12, 5-pole, A-coded
General data
Mounting method 2-hole screw mounting
Temperature range -20...+55 °C (storage temperature -40...+70 °C)
Protection IP67
Dimensions H×W×D 44×63×225 mm
Safe output
Switching current by safe output max. 2 A (short-circuit and overload protected)
Actuator supply UA 24 V DC (EN 61131-2), max. 9 A
Safe input
Sensor supply US 24 V DC (EN 61131-2), max. 200 mA (PIN 1+5), short-circuit and overload protected, or max. 700 mA for only one PIN
Type for electronical sensors or mechanical switches
Connections
Fieldbus Ethernet 10/100 Mbit/s; Push Pull RJ45 Data connector
Sensor-system/actuator supply Push Pull Power connector, max. 12 A
I/O ports M12, 5-pole, A-coded
PROFINET
Specification V2.2, Conformance Class C (IRT)
Addressing DCP
MRP yes
Shared Device/Input yes, for 2 controls
Safety Indicators
DC 98%
Service life 20 years
Category up to 4
PFH 1.653E-9
PL up to e
SIL CL up to 3
SIL up to 3
Diagnostic
Communication status via LED
Diagnostic via LED per module and channel
Diagnostic via BUS per module and channel
Actuator warning per channel via LED and BUS
Monitoring - under voltage yes
Monitoring - no voltage yes
Short-circuit and overload yes
Cross-link detection Sensor/Actuator
Wire break detection yes
Commercial data
country of origin DE
customs tariff number 85389099
EAN 4048879454216
eClass 27242604
Packaging unit 1.000
Data cableShow all
Power cableShow all
Sensor-actuator cableShow all

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 55563_Z10714-FEB16-OCT18-MVK.MPNIO-F-V2.2_PN_Z_C.PDF
  • Download Approvals and certificates 55563_02-03.16_CE_Z_C.PDF
  • Download Approvals and certificates 55563_01-205-5408-01-16_15.02.2021_TUEV_Z_B.PDF
  • Download Approvals and certificates 55563_E201820-NRAQ7_ULC_Z_A.PDF
  • Download Approvals and certificates 55563_E201820-NRAQ_UL_Z_A.PDF
  • Download Configuration Files 55562_63_MVK_F_KFG_X_12.ZIP
  • Download Drawing Files 55563_P8_2_50.ZIP
  • Download Drawing Files 55562_STP_X_A.ZIP
  • Download Drawing Files 55562_DXF_X_A.ZIP
  • Download Installation Instructions 55563_INA_X_17.ZIP
  • Download Manuals 55563_HDB_X_22.ZIP
  • Download Software and driver 55557_SISTEMA_TB3_X_22.ZIP
  • Download Software and driver 10500984_MVKSAFETY CONFIGURATOR_TB2_X_30.ZIP
