MASI67 I/O MODULE K3
Product kan afwijken van illustratie

MASI67 I/O MODULE K3

8 digital inputs, 8 digital, passive safety outputs
Artnr: 56415
Gewicht: 0.34 kg
  In productie
 Productvergelijking
Prijs per stuk:

Ook interessant voor U

Digital inputs/outputs
DI8 - 0.34 A DO8 - 1.6 A - 8× M12 (AB) (K3)
Output groups up to PLd (EN ISO 13849-1) can be switched off via safety relays
Double assignment of M12 females, PIN 2 + 4
Connection cables are in the online shop under "Connection Technology". Housing fully potted.
Input
Type for 3-wire sensors or mechanical switches, PNP
Sensor supply US max. 340 mA from AS-Interface (short-circuit and overload protected)
Technical Data
Bus voltage (AS-Interface) 26.5...31.6 V DC
Total current max. 440 mA
Addressing via built-in address port or master
Address range 1...62 (2× 1...31 A or B)
Profile (IO/ID/ID2 code) 2× S-7.A.7
Double assignment of M12 female yes
General data
Protection IP67
Mounting method DIN-rail mountable (EN 60715) or screw fixing
Temperature range -20...+60 °C (storage temperature -20...+70 °C)
Dimensions H×W×D 144×72×39 mm
Output
Supply voltage 24 V DC external (18...30.2 V DC) EN 61131-2, connection via black AS-Interface profile cable, 2 safely separated supplies possible
Switching current per output max. 1.6 A (short-circuit and overload protected)
Total current 2× 4 A
Diagnostic
Communication status via LED
Diagnostic via LED per module
Monitoring - no voltage yes
Commerciële gegevens
Douane tarief nummer 85176200
EAN 4048879048989
eClass 27371604
Land van oorsprong DE
Verpakkingseenheid 1

Gegevens Over Artikel:
  • Download Datablad
  • Download Approvals and certificates 56415_5034-04.16_ce_z_e.pdf
  • Download Approvals and certificates 56415_82801_asi_z_a.pdf
  • Download China RoHS information EPUP-20_CHR_x_1.pdf
  • Download Drawing Files 56415_p8_2_50.zip
  • Download Drawing Files 55033_p8_2_50.zip
  • Download Installation Instructions 56414_ina_6_16.pdf
  • Download Manuals 56431_hdb_x_25.zip
  • Download Manuals 56411_hdb_x_15.zip
