TREE M-5TX IP67 Lite managed Switch 5 Ports  58183
Product may differ from image

TREE M-5TX IP67 Lite managed Switch 5 Ports

5x10/100BT IP67
Art.No.: 58183
Weight: 0.26 kg
Country of origin:  DE
Available
 Product Comparison
List price per piece:
Download to Easy-Import-Export

Description

5 port managed switch
5× M12 (female), D-coded
Supply PIN 1/3
Connection cables are in the online shop under "Connection Technology".
Certificate
Certificate
Certificate

Technical Data
Operating voltage 9.5...31.5 V
Transfer rate 10/100 Mbit/s full duplex
Over voltage protection yes
Current consumption 130 mA, +/- 25 %
Operating modes Autocrossing Autonegotiation
Invers-polarity protection yes
General data
Mounting method 3 hole screw mounting
Temperature range 0...+60 °C (storage temperature -40...+85 °C)
Housing Black plastic
Protection IP67
Dimensions H×W×D 105×60×40 mm
Diagnostic
Communication status via LED, LLDP
Monitoring - no voltage yes
Switch Management
Protocols DHCP, SNMP (v1, v2c, v3), RSTP, STP, LLDP, NTP, RMON, SSH (CLI)
Port Mirroring yes
VLAN (QoS) IEEE 802.p yes
Alarm contact no
Remote maintenance Open VPN
Webserver HTTP, HTTPS
Switch Form Lite - Managed Switch
Connections
Fieldbus 5× M12 (female), D-coded
Supply 1× M12 (male), A-coded

ECLASS-6.0 19170106
ECLASS-6.1 19170106
ECLASS-7.0 19170106
ECLASS-8.0 19170106
ECLASS-9.0 19170401
ECLASS-10.1 19170401
ECLASS-11.1 19170401
ECLASS-12.0 19170401
ETIM-5.0 EC000734
customs tariff number 85176200
EAN 4048879718301
Packaging unit 1


Data Regarding Article:
  • Download Product-PDF
  • Download Approval: UL Listed CA 58183_E201820-NRAQ7_ulc_z_a.pdf
  • Download Approval: UL Listed US 58183_E201820-NRAQ_ul_z_a.pdf
  • Download Construction files: DXF 58180_dxf_x_a.zip
  • Download Construction files: P8 58183_p8_2_60.zip
  • Download Construction files: STP 58180_stp_x_a.zip
  • Download Document: Installation guide 58183_ina_x_11.zip
  • Download Document: User manual 58183_hdb_x_12.zip
  • Download Information: Certificate of conformity Murrelektronik GmbH 09-11-20_(3) RoHS REACh exception 6c 7cI_DoC_z_a.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 06-02-23_(3) China RoHS 2 25EEP_DoC_z_a.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Download Information: Certificate of conformity UKCA 58183_11-08.17_uk_z_a.pdf
  • Download Information: EU declaration of conformity 58183_11-08-17_ce_z_a.pdf
  • Download Information: MTTF Report 58183_SN29500(40°C)-Berechnung_mttf_p_a.pdf
