MIRO TR 24VDC SK OPTO-COUPLER MODULE  52510
Product may differ from image

MIRO TR 24VDC SK OPTO-COUPLER MODULE

IN: 53 VDC - OUT: 48 VDC / 0,5 A - 1 C/O contact
Art.No.: 52510
Alternative product:    6652510
Weight: 0.03 kg
Country of origin:  CZ
Out of Stock - Contact Us for Availability
 Product Comparison
List price per piece:

Description

Transistor 0.5 A
24 V DC
electr. NO/NC contact
Screw terminals
Certificates as JSON - filtered
Certificates as JSON - filtered

General data
Mounting method DIN-rail mountable (EN 60715)
Temperature range -20...+60 °C
Test isolation voltage 3.75 kV
Housing Black plastic, flame retardant
Dimensions H×W×D 91×6.2×71 mm
Output
Leakage current (output is open) max. 0.1 mA
Switching time ON/OFF 40/150 µs
Saturation voltage (across output) max. 1.2 V DC
Switching voltage 5...48 V DC
Switching frequency max. 10 Hz
Switching current per output 0.1 mA...0.5 A
Input
Control current 6 mA
Voltage range OFF 0...5 V DC
Voltage range ON 10...53 V DC
LED display LED (yellow)
Product article number of manufacturer 52510

ECLASS-6.0 27371604
ECLASS-6.1 27371604
ECLASS-7.0 27371604
ECLASS-8.0 27371604
ECLASS-9.0 27371604
ECLASS-10.1 27371604
ECLASS-11.1 27371604
ECLASS-12.0 27371604
ETIM-5.0 EC001504
customs tariff number 85414900
EAN 4048879026864
Packaging unit 1


Data Regarding Article:
  • Download Data Sheet
  • Download Approval: CSA CA 52510_080128-0-000_C3211-07_csa_z_b.pdf
  • Download Approval: CSA US 52510_080128-0-000_C3211-07_csau_z_b.pdf
  • Download Approval: UL Registered CA 52510_E140415-NKCR8_urc_z_d.pdf
  • Download Approval: UL Registered US 52510_E140415-NKCR2_ur_z_d.pdf
  • Download Construction files: DXF 52000_dxf_x_a.zip
  • Download Construction files: P8 52510_p8_2_60.zip
  • Download Construction files: STP 52000_stp_x_a.zip
  • Download Information: Certificate of conformity Murrelektronik GmbH 17-12.20_(3) China RoHS 2 25EEP_DoC_z_b.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 20-10.21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 09-11.20_(3) RoHS&REACh exception 6c&7cI_DoC_z_a.pdf
  • Download Information: Certificate of conformity UKCA 52510_1530-04.16_uk_z_a.pdf
  • Download Information: EU declaration of conformity 52510_1530-04.16_ce_z_b.pdf
  • Download Information: MTTF Report 52510_SN29500(40°C)-BerechnungV1.4_mttf_p_a.pdf
