AMMDS 10-44/1 OPTO-COUPLER MODULE  50082
Product may differ from image

AMMDS 10-44/1 OPTO-COUPLER MODULE

IN: 35 VDC - OUT: 35 VDC / 0.2 A
Art.No.: 50082
Alternative product:    526071
Weight: 0.036 kg
Country of origin:  CZ
Available
 Product Comparison
List price per piece:
Download to Easy-Import-Export

Description

Transistor 0.2 A
24 V DC
with minus plug link
Double terminals on the output side
for rapid switching
Certificate
Certificate

Input
Plug link (supplied) Art-No. 90960
Voltage range OFF 0...5 V DC
Voltage range ON 10...35 V DC
LED display LED (red)
Input current 10 mA
Output
Leakage current (output is open) max. 0.3 mA
Switching time ON/OFF 20/14 µs
Saturation voltage (across output) max. 0.5 V DC
Switching voltage 5...35 V DC
Switching frequency max. 20 kHz/200 Hz (resist./ind.)
Switching current per output 1 mA...0.2 A
General data
Mounting method DIN-rail mountable TH35 or G32 (EN 60715)
Temperature range -20...+60 °C
Test isolation voltage 2.5 kV
Housing Black plastic, flame retardant
Dimensions H×W×D 68×82×12 mm

ECLASS-6.0 27371604
ECLASS-6.1 27371604
ECLASS-7.0 27371604
ECLASS-8.0 27371604
ECLASS-9.0 27371604
ECLASS-10.1 27371604
ECLASS-11.1 27371604
ECLASS-12.0 27371604
ETIM-5.0 EC001504
customs tariff number 85414900
EAN 4048879027977
Packaging unit 1


Data Regarding Article:
  • Download Product-PDF
  • Download Information: Certificate of conformity Murrelektronik GmbH 06-02-23_(3) China RoHS 2 25EEP_DoC_z_a.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 09-11-20_(3) RoHS REACh exception 6c 7cI_DoC_z_a.pdf
  • Download Information: Certificate of conformity UKCA 50082_1514-04.16_uk_z_a.pdf
  • Download Information: EU declaration of conformity 50082_1514-04.16_ce_z_d.pdf
  • Download Information: MTTF Report 50082_SN29500(40°C)-BerechnungV1.4_mttf_p_b.pdf
